Touch Table

43 inch Multimedia touch table

LCD Panel	Name Type	43'' touch table
	Model Number	V439YM
	Panel size	43 inch
	Display Area	941.184(H) × 529.416(V) mm
	Aspect Ratio	16：9
	LCD Type	TFT-LCD
	Max Resolution	1920 × 1080
	Display color	16.7 M
	Brightness	300 cd/m²
	Contrast ratio	1200 : 1
	Viewing angle (up/down/left/right)	89°/89°/89°/89°
	Response Time	8ms
	Field Frequency	60Hz
	Color system	PAL/NTSC/Auto Identification
	OSD Language	Chinese/English
Touch screen parameter	Touch Style	Capacitive touch
	Touch Resolution	10 points
	Response speed	<15ms
	Accuracy of touch	More than 90% of the touch area ±2mm
	Touch ways	Fingers, touch pen and other opaque objects
	Output format	The coordinate output
	Clicks time	Unlimited
	The smallest touch size	5mm
	Light resistance	Yes available
	Touch Interfaces	USB
	Operating temperature &Humidity	-10℃ ~ +50℃，≤85%RH
	Storage temperature &Humidity	-20℃ ~ +60℃，≤90%RH
Computer configuration	CPU	I3
	DDR	4G DDR3
	HDD	500G
	WIFI	Support
Power	Audio system	Built-in 8 Ω 10 w * 2 speakers
	Power	AC100V～240V，50/60Hz
	The maximum power loss	≦200W
	Standby power loss	＜1W
Environment	Operating temperature	0℃~50℃
Environment	Storage temperature	-20℃~60℃
Instructions	Frame material	Toughened glass panel + hardware structure
	Body size (long x high x thick)	1099 × 693.9 × 650mm
	Installation type	Floor standing
	Range of application	Indoor
Accessories	Power cable	1
Accessories	Manual	1
